Application range
KX bottom silo discharger is specially designed in two or more bottom silos to convey material continuously to another equipment. The structure of KX bottom silo discharger is arranged reasonably. It can help to reduce the arrangement of other equipments and save investment
Technical characters:
Apply variable screw pitch, variable rotation direction and realize stable flow and feed material.
The housing is of pipe structure, characterized by good sealing, big conveying volume and no dust pollution.
It is characterized by good rigidity structure, stable driving and easy operation.
Technical parameters
|
specifications
|
Ф200
|
Ф290
|
|||||||
|
The feeding point spacing
m
|
2×1500
|
2×2000
|
2×2500
|
2×1500
|
2×2000
|
2×2500
|
2×3000
|
||
|
The speed type device drivers
|
throughput
m3/h
|
12
|
36
|
||||||
|
model
|
XWD4.0-5-35
|
XWD4.0-5-35
|
XWD5.5-5-35
|
||||||
|
power
KW
|
4.0
|
4.0
|
5.5
|
||||||
|
speed
rpm
|
40
|
40
|
|||||||
|
h
|
500
|
555
|
|||||||
|
r
|
150
|
150
|
|||||||
|
j
|
370
|
370
|
|||||||
|
Adjustable-speed type device drivers
|
throughput
m3/h
|
8～20
|
18～55
|
||||||
|
model
|
XWD5-17-YCTL180-4A
|
XWD5-17-YCTL180-4A
|
XWD6-17-YCTL200-4B
|
||||||
|
Power KW
|
7～70
|
||||||||
|
speed
rpm
|
4.0
|
4.0
|
7.5
|
||||||
|
h
|
500
|
555
|
470
|
||||||
|
r
|
150
|
150
|
275
|
||||||
|
j
|
370
|
370
|
380
|
||||||
|
Valve tone section way
|
I
|
Manual adjustment
|
|||||||
|
II
|
Luen shaft sprocket adjustment
|
||||||||
Renewal table 1
|
specifications
|
Ф350
|
Ф475
|
||||||||
|
The material mouth spacing
mm
|
2×1500
|
2×2000
|
2×2500
|
2×3000
|
2×1500
|
2×2000
|
2×2500
|
2×3000
|
||
|
The adjustable speed type device drivers
|
throughput
m3/h
|
64
|
160
|
|||||||
|
model
|
XWD5.5-5-35
|
XWD7.5-7-35
|
XWD11-8-35
|
XWD15-9-35
|
||||||
|
power
KW
|
5.5
|
7.5
|
11.0
|
15.0
|
||||||
|
speed
rpm
|
40
|
40
|
||||||||
|
h
|
570
|
510
|
590
|
630
|
||||||
|
r
|
150
|
320
|
380
|
480
|
||||||
|
j
|
370
|
420
|
480
|
560
|
||||||
|
Adjustable speed type device drivers
|
throughput
m3/h
|
32～59
|
80～225
|
|||||||
|
model
|
XWD6-17-YCTL200-4B
|
XWD8-17-YCTL225-4A
|
XWD9-17-YCTL225-4B
|
XWD10-17-YCTL250-4A
|
||||||
|
power
KW
|
7.5
|
11
|
15
|
18.5
|
||||||
|
speed
rpm
|
7～70
|
|||||||||
|
h
|
490
|
520
|
625
|
570
|
||||||
|
r
|
275
|
380
|
480
|
500
|
||||||
|
j
|
380
|
480
|
560
|
630
|
||||||
|
Valve adjusting mode
|
I
|
Manual adjustment
|
||||||||
|
II
|
Luen shaft sprocket adjustment
|
|||||||||
Contour map
Basic dimensions
